Buy Single Crank Precision Press Machine Price

Specification	unit	APS-100		APS-150		APS-200		APS-250		APS-260		APS-300		APS-400		APS-500		APS-600		APS-800		APS-1000
Capacity	Tons	100	100	150	150	200	200	250	250	260	260	300	300	400	400	500	500	600	600	800	800	100
Rated tonnage point (above B.D.C)	mm	3	6	4	6.5	4	7	4	7	4	7	9	7	8	9	13	7	12	9	12	9	13
Stroke	mm	40	180	40	200	40	250	40	250	40	200	300	250	250	300	350	300	350	300	350	300	350
Stroke per minute	spm	80-180	20-45	80-150	20-40	60-130	20-40	50-110	20-40	50-110	20-40	20-35	20-35	20-35	15-30	10-25	15-30	10-25	15-30	10-20	15-25	15-25
Die height(S.D.A.U)	mm	290	450	310	500	350	550	380	550	380	550	650	550	550	600	700	650	700	700	700	700	900
Maximum counterbalancer capacity	kg	800	800	800	800	1000	1200	800	800	1200	1200	1500	1500	1000	1500	1500	1500	3000	3000	4000	4000	5000
Slide adjustment	mm	100	100	100	120	100	150	100	150	100	150	150	150	150	150	150	150	200	200	200	200	300
Slide area(L.RxF.B)	mm	700x600	700x600	700x700	700×700	800x800	800x800	900×800	900x800	1000×900	1000x900	1060x900	1060×900	1100x1050	1100x1050	1200x1200	1100x1000	1500x1300	1500x1300	1800x1400	1800x1400	1900x1600
Bolster area (L.RxF.B)	mm	700x700	700x700	800x700	800x700	900x900	900x900	900x900	900×900	1000x1000	1000x1000	1100×1000	1100x1000	1200×1100	1200x1100	1300x1100	1200x1100	1500x1300	1500x1300	1800x1400	1800x1400	1900x1600
Bolster thickness	mm	140	140	150	150	170	170	180	180	180	180	200	200	200	200	220	220	250	250	280	280	300
Slisde opening	FBxH	400x400	400x400	450x300	300x300	400x400	300x400	400x300	350x300	500x300	400x500	400x500	400x500	400x500	400x500	500x650	450x600	900x700	900x700	900x700	900x700	1000x800
Height of the top surface of bed from floor level	mm	840	840	830	830	850	750	1060	1060	600	700	750	850	900	950	800	800	800	800	600	600	600
Work energy	kg-m	300	750	700	1000	800	1500	1000	2000	1000	2000	3000	2500	3000	3500	7000	3800	9000	7000	11000	10000	16000
Main motor	Kwxp	15x4	15x4	22×4	22×4	22x4	22×4	30x4	30x4	30x4	30x4	30x4	30×4	37.0x4	37.0x4	45x4	45×4	75×4	75×4	90x4	90x4	110x4
Slide adjusting motor	Kwxp	1×4	1×4	2x4	2x4	2×4	2x4	2×4	2×4	2×4	2x4	2x4	2x4	2x4	2x4	3x4	3×4	3x4	3x4	3x4	3x4	5x4
Frame structure		one piece frame

● The advance technical optimized structure of machine

● The machine body is welded high quality steel sheet and treated by tension elimination

● The key parts are treated by hard chrome plated/nitrogen

● Adopted well known contoller/driving unit/electromagnetism clutch equipments, bearing etc

● Intemational technology class for press machine, measures machine specification

● High quality & high response multi -function processor

● High memory / program with specialized design

● Shift driving with high integration multishaft / spreading automatic equipments

● LCD man-machine interface / high frequency response control /Connection teminalof intemational website & USB

● (Optional:DC shift driving / frequency shift driving/ servo shift driving / closed loop/ spreading capacity/ LCD)

APS Series Single Crank Precision Press Machine
