AOTAI Two Platen Machine Series

NTERNATIONAL CLASS NO 680/5180 750/6080 1180/9780 1380/11580 1450/11580
SPECIFICATION Z/680 Z/750 Z/1180 Z/1380 Z/1450
Screw type	A	B	C	D	A	B	C	D	A	B	C	D	A	B	C	D	A	B	C	D
Injection Unit
Screw diameter mm	90	95	100	105	90	95	105	110	110	115	120	125	110	120	130	140	110	120	130	140
Screw L/D ratio L/D	23.2	22	20.9	19.9	23.2	22	19.9	19	23	22	21.1	20.3	25.1	23	21.2	19.7	25.1	23	21.2	19.7
Shot volume (theoretical) CM²	2926	3260	3612	3982	3085	3437	4199	4608	5270	5760	6272	6806	5559	6616	7765	9006	5559	6616	7765	9006
njection weight (PS) 9	2663	2967	3287	3624	2807	3128	3821	4193	4796	5242	5708	6193	5059	6021	7066	8195	5059	6021	7066	8195
njection rate g/s	579	645	715	788	574	640	782	858	793	867	944	1024	752	895	1050	1218	752	895	1050	1218
Iniection pressure Mpa	177	159	143	130	195	175	143	130	186	170	156	144	208	175	149	128	205	172	147	127
Screw speed rpm	150				115				90				90				90
Clamping Unit
Clamping force KN	6800				7500				11800				13800				14500
Space between tie-bars(W*H) mm	1040×910				1110×960				1260×1100				1380×1280				1480×1380
Max.mould height mm	950				1000				1200				1400				1450
Min.mould height mm	350				400				450				600				700
Ejector stroke mm	250				300				350				360				400
Ejector force KN	150				210				248				248				280
Max.Daylight mm	1750				1850				2400				2900				3100
Mould Opening Stroke mm	1400/800				1450/850				1950/1200				2300/1500				2400/1650
Max.mold weight t	9.5				11				16				23				27
Others
Pump max.pressure Mpa	21/16				21/16				21/16				21/16				21
Pump motor power (servo) KW	30+37+3.75				37+37+7.5				45+55+7.5				55+55+7.5				55+55+7.5
Heating power KW	42.95				56.7				66.1				86				86
Numbers of heating area Segmen	5+1				6+1				6+1				6+1				7+1
Machine dimension (LWH) M	7.4×2.6×2.98				8.7×2.5×3.2				9.5×3.3×3.4				11.7×3.55×4.2				12.5×3.65×4.3
Oitank cubage L	770				940				1500				1600				1600
Machine weight TON	27				31				48				65				75
